These ports are used for the deployment of Riedel software and cluster maintenance while using the Riedel Software Manager (RSM) and are not required during system runtime of the Riedel software such as Virtual SmartPanel and STAGE.
|
Name |
Port |
Port Configurable |
TCP or UDP |
|---|---|---|---|
|
SSH |
22 |
|
TCP |
|
Nomad-API |
4646 |
|
TCP |
|
Consul API |
8500 |
|
TCP |
|
ues-node-manager-api |
9900-9901 |
|
TCP |
Default Ports for Other Applications During Runtime
During system runtime, additional ports must be open between the Nodes according to your system deployment. These are listed in the corresponding user manual.
-
STAGE: Default Ports
-
SAME DSP Engine: SAME DSP Engine Default Ports
