This page describes the hiPush18 (Mark 3) Hardware Panel and its specifications.
hiPush18 (Mark 3)
Mark 3
19" 1RU Hardware Panel with 18 buttons and 2 rotary encoders for operation of the hi system. Each button has an LCD display (64 x 32 pixels) that shows its assigned function.
Dimensional Views
Front View
hiPush18 Mark 3 Front View.
Rear View
hiPush18 Mark 3 Rear View.
Top View
hiPush18 Mark 3 Top View.
Product View
hiPush18 Mark 3 Front View.
Specifications
|
Regulatory Model |
HI-PNL006 |
|---|---|
|
Lifecycle Status |
Current |
|
Number of Switches |
18 |
|
Number of Encoders |
2 |
|
Weight |
1020 g |
|
Housing Type |
1 Rack Unit |
|
Dimensions |
483 x 44 x 44 mm (W x H x D) |
|
Network Connection |
RJ45, 100Base-T Ethernet |
|
Operating Temperature Range |
10 °C to +35 °C |
|
Storage Temperature Range |
-10 °C to +50 °C |
|
Switch Operating Force |
1.7 ± 0.5 N |
|
Input Voltage |
12 V DC |
|
Power Consumption |
Max. 20 W |
|
External PSU |
Official hiPSU (ordered separately)
|
|
Power Connector Type |
WAGO 713 Series 6-pin |
|
Protection Class |
IP20 |
|
Conformity Marking |
CE |
|
CB Safety Certification |
IECEE CB Certificate SE-118960 (IEC 62368-1:2023) |
|
Regional Declarations |
European Union (CE)
|
|
Electromagnetic Compatibility (EMC) |
acc. to EN 61000-3-2:2019
|
|
EMC Immunity to Interference |
acc. to EN 55035:2017 |
|
EMC Emission of Interference |
acc. to EN 55032:2015 |
|
RoHS compliant |
acc. to EN IEC 63000:2018 |
The product label identifies the regulatory model as HI-PNL006.
Warning
Use only with the official hiPSU.
Ordering Information
The regulatory model in Specifications identifies the product for compliance purposes; the SAP SKU below is used for ordering.
|
Item |
SAP SKU |
Description |
|---|---|---|
|
hiPush18 |
9302865 |
19" 1RU panel with 18 high-contrast full-size LCD buttons and 2 rotary encoders with position meters. Operation requires hiGlue and one hiUser session. The hiPSU is not included and must be ordered separately. |
|
hiPSU |
9302879 |
External PSU for hiPush and hiContact. |
Power Connector Pinout
For pin assignments, see Power Connector Pinout.
